Fully Automatic Oill Filling Machine Bottles 3000BPH For Sale





Quantity:

Fully Automatic Oill Filling Machine Bottles 3000BPH

Product Description
Fully Automatic Oill Filling Machine Bottles 3000BPH

Product introduction:

This is our newly developed filling machine . It has reached the international advanced level ,partial has exceeded the similar product . It is abroad , also certified by the world famous chemical magnate . This is a inline piston filling machine for cream and liquid ..It adopts PLC and touch screen control panel for control material . It is characterized by accurate measuring ,advanced structure ,stable operating ,low noise ,large adjusting range ,fast filling speed . It is also suitable for the filling of easy volatilization ,easy bubbly liquid strong corrosive liquid for rubber ,plastic,and high viscosity ,liquid ,semi-liquid . Operators adjust and meter figure in the touch screen control panel , also can adjust metering of each filling head . The external surface of this machine is made of excellent stainless steel . Good appearance , applied to GMP standard .

Type
Head
Suitable bottles
Capacity(bottle/hour)
Precise
Size of Machine(mm)
Power(kW)
Power source
Air source
Note
YG-Z-20D
20
Can be customized
200ml:≤7500
1000ml:±2ml
2400*1100*2200
2.5kw
220/380V
50/60Hz
0.6MPa
Can be customized
YG-Z-16D
16
200ml:≤6500
2000*1100*2200
2.5kw
YG-Z-12D
12
200ml:≤5000
2000*1100*2200
2kw
YG-Z-8D
8
200ml:≤3500
1800*1100*2200
2kw


Machine Details:



NO.1

1.Quantitative filling, adjustment for one key on touch screen.

2.Adopt fast connect, easy to disassembly and wash, without dripping

3.Diving mode filling.

NO.2

1.High quality three – way valve, no dead Angle, no residue.

2.One key to clean residual material on cylinders.

Different choices of filling Needles:

According to different customer requirements, we use a variety of different filling nozzles, used to fix to variety of viscosity, temperature and other conditions of the filling materials.



Different choices of pipes:

According to the customer’s different choice, can be equipped with different materials of pipe, to meet the customer
variety of different liquid safe filling

 Food grade rubber hose



   Food-grade silicone hose

      Teflon corrugated pipe

Different choices of Piston rings:

The piston ring is resistant to wear. It has spring coil inside the piston ring. After minor wear, it has automatic
correction function,the cylinder won’t happened leakage.

Food-grade piston rings

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine.

Industrial-grade piston rings

Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine.

Bottle unscrambler

Different choice of Bottle unscrambler Machine

According to customers’ requirements of different bottles and different production speed, we can use different kinds of automatic bottle unscrambler machines, and we can customize machines for customers to meet different production conditions.

Fully Automatic Bottle Unscrambler Machine

The machine consists of bottle feeder, host machine and conveying motor .PLC control system combines all the driving device together. The set figures can be alternated via touch screen panel to meet your different requirement. It is only necessary to change rotary plate in the bottle sorting barrel targeting different materials, and other parts can be freely adjusted . The machine is mainly made of stainless steel 304 and aluminum alloy , strictly based on GMP.

Horizontal Bottle Unscrambler Machine

This machine is controlled by PLC and touch  screen,operators can adjust all parameters on

the touch screen .frequency control the speed.

Operators only need to change the turntable

of the unscramble box in order to change the specification ,other parts can be adjusted.

Rotary Bottle Accumulation table

The rotary table of the machine adopts variable frequency stepless speed regulation for rotary movement, so that the bottle enters the conveyor belt in sequence under the action of rotating tangential force, and is matched with the packaging production line to achieve the purpose of saving labor and improving production efficiency. This machine is used for power on, easy to operate.

Capping machine

Linear Screw Capping Machine.

              This machine is suitable for glass bottle and plastic bottle ,screw/thread caps twisting ,it can used in a
wide range of bottles(with differen top diameter ), by adjust the machines but not change parts. Also,the speed is quicker than disc capper.
Advantage : for different size bottles and caps, it do not need to change any part. The machine can be
adjust from right & left, up and down, very convenience.

High hardness silica gel roller

Adopt high hardness silica gel wheel,Not easy to abrasion, don’t need frequently change.

The cap elevator machine

Can be equipped with a cap elevator, easy to add caps.

Labeling machine

Automatic Double-side Labeling Machine:

This machine id widely suitable for foodstuff, cosmetic, pharmaceutical, pesticide and other industries. It is single
and double side labeling for flat, square and round bottle which volume below 1L. Automatic controlled by computer
(PLC)easy operating.

Machine introduction:

1.Adopt mature PLC control technology, make the machine stable and high-speed.Can be suitable or square /oval flat bottles at the same time.

2. Adopt touch screen control system, simple, practical and efficient operation.

NO.1

Adopt high quality wheel to leave some space between the bottles, so as to ensure that the labels will not be missed. The rotary speed of the sponge wheel can be adjusted to adjust space space between the two bottles.

NO.2

The parts of the machine that store labels and collect label paper are designed to be adjustable to accommodate a wide variety of labels.

NO.3

Adopt photoelectric equipment imported from Germany,and high quality servo motor, the labeling accuracy is greatly improved.

 CompanOur Services

1. Installation, debug
After equipment reached the workshop of customer, place the equipment according to plane layout we offered. We will arrange seasoned technician for equipment installation, debug and test production at the same time make the equipment reach the rated producing capacity of the line. The buyer need to supply the round tickets and accommodation of our engineer, and the salary.

2. Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. Seasoned technician will guide and establish training outline. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.

3. Quality guarantee
We promise that our goods are all new and not used. They’re made of suitable material, adopt new design. The quality, specification and function all meet the demand of contract.

4. After sales
After checking, we offer 12 months as quality guarantee, free offer wearing parts and offer other parts at the lowest price. In quality guarantee, the technician of buyers should operate and maintain the equipment according to seller’s demand, debug some failures. If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems. The cost of technician arrangement you could see the cost treatment method of technician.

After quality guarantee, we offer technology support and after sales service. Offer wearing parts and other spare parts at favorable price; after quality guarantee, the technician of buyers should operate and maintain the equipment according to seller’s demand, debug some failures. If you could not solve the problems, we will guide you by phone; if the problems are still can not solve, we will arrange technician to your factory solving the problems.

FAQ

Q1: Do you have reference project?
A1: We have reference project in most countries,If we get the permission of the customer who has brought the machines from us ,we can tell you their contact imformation,you can go to vist their factory.
And you are always welcome to come to visit our company,and see the machine running in our factory,we can pick you up from the station near our city.

Contact our sales people you can get video of our reference running machine

Q2: Do you provide customized service
A2: We can design the machines according your requirements(materil ,power,filling type,the kinds of the bottles,and so on),at the same time we will give you our professional suggestion,as you know,we have been in this industry for many years.

Q3:What’s your guarantee or the warranty of the quality if we buy your machines?
A3: We offer you high quality machines with 1 year guarantee and supply life-long technical support.

Q4: How long time for installation?
A4: According your machines order,we will send one or two engineers to your plant,it will take about 10 days to 25 days.
